应用与概述/Brief Introduction：

该线由双曲线式罗杆洗瓶缺水内置式机、服食液罐装轧盖机二台单机联机版组合，分成擦洗、缺水高压蒸汽灭菌方法和罐装封膜三大上班区，全部可协作加工，也可单机联机版用到。可顺利完成淋水、超声心动图波擦洗、冲水、冲气、缺水高压蒸汽灭菌方法、放凉、罐装、理盖、戴盖、轧盖等繁琐流程。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

显著特点/Characteristic：

用于超声频率波清晰及热气变化冲干净、远红外高温天气杀菌、双头罐装与密封等技能。整线联调自動把控好。进行简洁便宜，推动了电气自动化一身化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技木运作/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
可用于品种 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(另外没问题办公36Kw)(including normal working 36 kw)
丝机净重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
